Flexible electric strike offers value and innovation in one compact product. Horizontal adjustability and small body design eliminates need to cut out the dust box making this a great option for retrofit applications.
Product Overview
The flexible, compact AES-300 electric strike offers value and innovation in one compact product. The small body design eliminates the need to cut out the dust box during installation, making this a great option for retrofit applications where size restraints may occur. Offering up to 1/4” horizontal adjustability, the AES-300 is ideal for cylindrical locksets with a latch up to 5/8” throw without a deadbolt.
Product Features
- Strike body depth 1-3/16"
- For use with 5/8" cylindrical locksets
- Non-handed for easy installation
- Small body design eliminates the need to cut out the dust box
- Available in fail secure only
Certifications
- Certifications : UL 1034 - Standard for Burglary-Resistant Electric Locking Mechanisms
Strength & Durability
- Holding Force : 1000
- Dynamic Strength : 50
Electrical
- Current 12v DC : 200
- Current 24v DC : 100
- Current 12v AC : 200
- Current 24v AC : 100
- Input Operating Voltage : Available in either 12 or 24 VAC or VDC
