General Features
- Cabinet lock - deadbolt drawer lock
- Easily rekeyable via cylinder release mechanism
- Will accept other manufacturer's Schlage compatible deadbolt cylinders
- (Grade 1) ANSI/BHMA No. E07041
- 800LCA barrel length: 1-1/8"
- 800LCM barrel length: 1-3/8"
- Barrel diameter: 1-1/8"
- Bolt projection: 7/8"
- 26D, US3 or 10B finish
- Packed 10 per box
- US Patent Nos: 4,899,563; 4,920,774
- WARNING (California Proposition 65)
Available Separately
- Plastic spacers 10-348, 10-349, 10-350
- Angle strikes 12-1, 12-2, 12-3
- Bar strikes 56-1, 10-054, 10-055, 10-057, 10-058
- Slotted strikes 10-052, 12-5
- Frameless drawer strike 12-4
- Trim ring TR78
- Through-bolt trim plate 1/8" thickness ETS1-125
- Through-bolt trim plate 1/4" thickness ETS1-250
- Through-bolt trim pull ETS1-PL
- Through-bolt trim spacer template ETST1
- Conversion kit for KABA-Peaks cylinders 78-KABA-CONV
Includes
- 2 ea. plastic spacers (included with 1-1/8" barrel length locks only) 10-350
- 1 ea. 1/4" plastic bar strike (included with 1-1/8" and 1-3/8" barrel length locks) 10 054
- 1 ea. 1/2" plastic bar strike (included with 1-1/8" barrel length locks only) 10-055
Keying
- N/A - this lock is sold less cylinders
- See our Schlage C keyway compatible cylinders 78-201 Series
- Will accept other manufacturers' Schlage-compatible deadbolt or key-in-knob cylinders
- Accepts Assa cylinder #6561: www.assalock.com
- Accepts Medeco cylinders: #20-009S4-ORIGINAL, #20-008S4-ORIGINAL, #20W009S4-BIAXIAL, #20W008S4-BIAXIAL, #20K009S4-KEYMARK, #20W200S1-KEY-RETAINAING ONLY: www.medeco.com
